DIMENSIONS AND WEIGHTS
STRANDED COPPER CONDUCTORS 600/1000V
Unarmoured and armoured, PVC over sheathed cables.
SINGLE CORE



Nominal Area of Conductor Thickness of Insulation Unarmoured Approximate overall diameter  Unarmoured Approximate cable weight  Armour wire diameter Armoured Approximate overall diameter Armoured Approximate cable weight
mm sq  mm mm kg/km mm mm kg/km
25
35
50
70
95

120
150
185

240
300
400

500
630
800
1000

1.2
1.2
1.4
1.4
1.6

1.6
1.8
2.0

2.2
2.4
2.6

2.8
2.8
2.8
3.0

12.9
14.0
15.1
16.9
19.4

21.0
23.2
25.8

29.0
32.1
35.8

39.6
43.8
48.3
53.7

345
450
600
810
1110

1350
1350
2060

2670
3320
4190

5230
6630
8330
10440

-
-
1.25
1.25
1.25

1.60
1.60
1.60

1.60
1.60
2.00

2.00
2.00
2.50
2.50

-
-
19.1
21.1
23.4

26.3
28.3
30.8

34.1
37.0
42.0

45.6
49.7
55.8
61.0

-
-
780
1030
1330

1680
2000
2430

3090
3770
4830

5920
7420
9500
11760
