| Nominal
Area of Conductor
|
Thickness
of Insulation |
Unarmoured Approximate overall diameter |
Unarmoured
Approximate cable weight |
Armour
wire diameter
|
Armoured
Approximate overall diameter
|
Armoured
Approximate cable weight
|
16
25
35
50
70
95
120
150
185
240
300 |
1.0
1.2
1.2
1.4
1.4
1.6
1.6
1.8
2.0
2.2
2.4 |
21.6
22.9
25.4
29.2
33.0
38.3
41.8
46.3
51.3
58.0
64.6 |
500
650
780
1050
1380
1950
2320
2840
3520
4530
5620 |
1.60
1.60
1.60
1.60
2.00
2.00
2.00
2.50
2.50
2.50
2.50 |
26.3
27.8
30.7
35.4
39.2
44.3
49.3
53.6
59.0
65.7
72.0 |
1170
1380
1610
2240
2690
3420
4360
5050
6010
7310
8650 |
