| Nominal
Area of Conductor
|
Thickness
of Insulation |
Unarmoured Approximate overall diameter |
Unarmoured
Approximate cable weight |
Armour
wire diameter
|
Armoured
Approximate overall diameter
|
Armoured
Approximate cable weight
|
16*
25*
35*
50**
70**
95** |
1.0
1.2
1.2
1.4
1.4
1.6 |
18.6
18.4
20.1
22.8
25.5
29.3 |
340
380
440
620
810
1080 |
1.25
1.60
1.60
1.60
1.60
2.00 |
21.9
23.0
24.8
27.8
30.4
35.5 |
770
940
1110
1330
1580
2220 |
