| Number
of Cores |
Nominal
cross-sectional area of Conductor
|
Thickness
of Insulation
|
Armour
wire Diameter
|
Approximate
overall cable Diameter
|
Approximate
Cable weight
|
| |
Mm2 |
mm |
mm |
mm |
Kg/km |
7
12
19
27
37
48 |
1.5 |
0.60 |
0.90
1.25
1.25
1.60
1.60
1.60 |
15.2
19.4
22.2
26.7
29.2
32.9 |
252
390
570
780
1020
1300 |
7
12
19
27
37
48 |
2.5 |
0.70 |
1.25
1.25
1.60
1.60
1.60
2.00 |
18.0
22.4
26.6
30.7
34.0
39.5 |
330
540
780
110
1410
1810 |
7
12
19
27
37
48 |
4 |
0.80 |
1.25
1.60
1.60
2.00
2.00
2.00 |
20.5
26.8
30.5
37.1
40.8
46.0 |
480
780
1170
1650
2320
3020 |
