| Nominal
Area of Conductor
|
Thickness
of Insulation
|
Unarmoured
Approximate overall diameter |
Unarmoured
Approximate cable weight |
Armour
wire diameter
|
Armoured
Approximate overall diameter |
Armoured
Approximate cable weight
|
50
70
95
120
150
185
240
300
400
500
630
800
1000 |
1.4
1.4
1.6
1.6
1.8
2.0
2.2
2.4
2.6
2.8
2.8
2.8
3.0 |
15.1
16.9
19.4
21.0
23.2
25.8
29.0
32.1
35.8
39.6
43.8
48.3
53.7 |
280
360
480
570
690
860
1090
1340
1670
2060
2440
2940
3750 |
1.25
1.25
1.25
1.60
1.60
1.60
1.60
1.60
2.00
2.00
2.00
2.50
2.50 |
19.1
21.1
23.4
26.3
28.3
30.8
34.1
37.0
42.0
45.6
49.7
55.8
61.0 |
460
570
700
890
1030
1220
1500
1770
2250
2700
3130
3890
4790 |
