| Nominal
Area of Conductor
|
Thickness
of Insulation |
Unarmoured Approximate overall diameter |
Unarmoured
Approximate cable weight |
Armour
wire diameter
|
Armoured
Approximate overall diameter
|
Armoured
Approximate cable weight
|
1.5*
2.5*
4*
6*
10*
16*
25**
35**
50**
70**
95**
120**
150**
185**
240**
300**
400** |
0.6
0.7
0.8
0.8
1.0
1.0
1.2
1.2
1.4
1.4
1.6
1.6
1.8
2.0
2.2
2.4
2.6 |
----
----
----
----
----
21.6
22.9
25.4
29.2
33.0
38.3
41.8
46.3
51.3
58.0
64.6
72.0 |
----
----
----
----
----
540
690
950
1260
1700
2310
2880
3520
4390
5760
7160
9040 |
0.90
0.90
0.90
0.90
1.25
1.25
1.60
1.60
1.60
1.60
2.00
2.00
2.00
2.50
2.50
2.50
2.50 |
135
15.0
17.8
19.2
22.8
26.3
27.8
30.7
35.4
39.2
44.3
49.3
53.6
59.0
65.7
72.0
81.3 |
280
350
460
550
880
990
1280
1610
2010
2520
3520
4200
4960
6390
8020
9710
11850 |
