| Nominal
Area of Conductor
|
Nominal
Area of Neutral Conductor |
Thickness
of Insulation
|
Unarmoured
Approximate overall diameter
|
Unarmoured
Approximate cable weight |
Armour
wire diameter |
Armoured
Approximate overall diameter |
Armoured
Approximate cable weight
|
25**
35**
50**
70**
95**
120**
150**
185**
240**
300**
300**
400** |
16
16
25
35
50
70
70
95
120
150
185
185 |
1.2
1.2
1.4
1.4
1.6
1.6
1.8
2.0
2.2
2.4
2.4
2.6 |
22.9
24.7
28.3
32.0
37.5
41.4
44.7
49.9
56.0
62.2
64.2
69.6 |
1260
1590
2120
2890
3920
4890
5900
7400
9590
11910
12190
15470 |
1.60
1.60
1.60
2.00
2.00
2.50
2.50
2.50
2.50
2.50
2.50
3.15 |
27.8
29.5
33.1
38.0
43.7
49.0
52.0
57.2
63.7
69.8
71.8
78.6 |
2020
2430
3050
4220
5460
6990
8180
9910
12470
15080
15360
19470 |
